Docol PHS 1800M Hot Formed Steel (PHS)
Docol PHS 1800M hot-formed steel is integrated with a small amount of boron in the alloy to improve hardness. This steel is widely developed for parts made by direct or indirect hot forming in the automotive industry.
Big fire special steel, high strength steel plate, steel industry supply and demand, steel suppliers
Docol PHS 1800M Hot Formed Steel (PHS) Description
Hot-formed steel is a type of steel that changes its structure and properties through thermo-mechanical processing (such as rolling, forging, extrusion, etc.) under high temperature. Hot-formed steel is widely used in automobile, aerospace, shipbuilding and other industries due to their advantages of high strength, good formability, and fatigue resistance. Hot-formed steel is more ductile than cold-formed steel, meaning it can deform under greater bending and tensile conditions and is more difficult to break. Therefore, Docol PHS 1800M hot-formed steel is suitable for material applications such as structural parts that need to withstand bending and deformation in use. Besides, the weldability of hot-formed steel is better than that of cold-formed steel, so Docol PHS 1800M hot-formed steel can be joined and assembled more easily.
Mechanical Properties
|
Steel Grade |
Standard |
Status |
Test Direction |
Yield Strength Rp0.2 (MPa) |
Tensile Strength Rm (MPa) |
Extension Rate A80( %) |
Extension Rate A5( %) |
|
Docol PHS FH 1800 |
SSAB |
Full hard |
T |
970 |
1070 |
4 |
- |
|
Docol PHS CR1800 |
SSAB |
Fire after delivery |
T |
350 |
500 |
27 |
- |
|
Docol PHS CR1800 |
SSAB |
Hot printing |
T |
1300 |
1800 |
6 |
- |
Chemical Composition
|
Brand |
C (max %) |
Si (max %) |
Mn (max %) |
P (max %) |
S (max %) |
Cr (max %) |
B (max %) |
|
Docol PHS CR1800 |
0.27-0.33 |
0.15-0.35 |
1.00-1.45 |
0.025 |
0.010 |
0.35 |
0.0008-0.0050 |
