Docol 1300M Martensitic Steel (MS)
Docol 1300M: A Docol martensitic steel Docol1300M martensitic steel with ultra-high tensile strength helps to improve crashworthiness and provides reliable guarantee for lightweight design and cost-effective production in the automotive industry. Docol is one of the cold-rolled high-strength steels on the market and has become a material for applications such as side anti-collision beams, bumpers and structural parts in the automotive industry.
Big fire special steel, high strength steel plate, steel industry supply and demand, steel suppliers
Docol 1300M Martensitic Steel (MS) Description
Docol 1300M: A Docol martensitic steel Docol1300M martensitic steel with ultra-high tensile strength helps to improve crashworthiness and provides reliable guarantee for lightweight design and cost-effective production in the automotive industry. Docol is one of the cold-rolled high-strength steels on the market and has become a material for applications such as side anti-collision beams, bumpers and structural parts in the automotive industry.
Mechanical Properties
Steel Grade | Standard | Plating | Test Direction | Yield Strength Rp0.2 (MPa) | Tensile Strength Rm (MPa) | Extension Rate A80 (min %) | BH2 (Min MPa) | 90 ° Bend the Most Small Bend Inner Diameter |
Docol CR1030Y 1300T-MS | VDA239-100: 2016 | UC, eg. | L | 1030-1330 | 1300-1550 | 3 | 30 | 3.5xt |
Chemical Composition
C (max %) | Si (max %) | Mn (max %) | P (max %) | S (max %) | Al (min %) | Nb Title (max %) | Cr Mo (ma%) | B (max %) | Cu (max %) |
0.16 | 0.40 | 1.80 | 0.020 | 0.010 | 0.015 | 0.10 | 1.00 | 0.005 | 0.20 |
Plating
Plating Type | Plating Grade | Standard | Single-sided coating quality, single-point test (g/m2) | Single side thickness, for reference only(μm) |
EG | ZE25/25 | EN 10152 | 12- | 1.7- |
EG | ZE25/50 | EN 10152 | 29- | 4.1- |
EG | ZE25/75 | EN 10152 | 47- | 6.6- |
EG | ZE25/100 | EN 10152 | 65- | 9.1- |
