Manganese Steel Plate
Manganese Plate is the ideal solution for cases where severe wear is combined with shocks or high pressure capable of work-hardened its austenitic structure. Used in jaws of crushers, hammers or pulverizers, cutting edges of large excavators, liners of shotblasting units, cores and wall of parpen moulds, and screens.
Big fire special steel, high strength steel plate, steel industry supply and demand, steel suppliers
Manganese Steel Plate Description
Manganese steel, also called Hadfield steel or mangalloy, is a steel alloy containing 12-14% manganese. Renowned for its high impact strength and resistance to abrasion in its hardened state, the steel is often described as the ultimate work hardening steel.
Product Parameters
Product Name | Manganese Steel Plate |
Production Process | Hot Rolling, Cold Rolling |
Material Standards | AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc. |
Width | 100mm-3000mm |
Length | 1m-12m, or Customized Size |
Thickness | 0.1mm-400mm |
Delivery Conditions | Rolling, Annealing, Quenching, Tempered or Standard |
Surface Process | Ordinary, Wire Drawing, Laminated Film |
Chemical Composition
| Jiuzhou Metal is an austenitic, non-magnetic steel produced to A128 specifications. | |
| Carbon | 1.05 - 1.2 |
| Manganese | 11.5 - 14 |
| Silicon | 1.00 Max |
| Phosphorus | 0.07 Max |
Mechanical Properties
| Tensile Strength | 125 ksi |
| Yield Strength | 52 ksi |
| Elongation in 2” | 45 % |
Scope of Application
Because of its self hardening properties, manganese steel has been used in the mining industry for many years – cement mixers, rock crushers, crawler treads for tractors, elevator and shovel buckets – as well as in the rail industry (switches and crossings) and other high impact environments.
