DIN 17155 Pressure Vessel Steel Plate
DIN 17155 pressure vessel steel plate is steel for boilers and pressure vessels. In addition to boilers and pressure vessels, DIN 17155 pressure vessel steel is also used to manufacture high-temperature liquid delivery pipes.
Big fire special steel, high strength steel plate, steel industry supply and demand, steel suppliers
DIN 17155 Pressure Vessel Steel Plate Description
DIN 17155 pressure vessel steel plate is boiler and pressure vessel steel. In addition to boilers and pressure vessels, DIN 17155 pressure vessel steel is also used to manufacture high-temperature liquid transportation pipelines.
Product Parameters
Product Name DIN 17155 Pressure Vessel Steel Plate Production Process Hot Rolling, Cold Rolling Material Standards AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc. Width 100mm-3000mm Length 1m-12m, or Customized Size Thickness 0.1mm-400mm Delivery Conditions Rolling, Annealing, Quenching, Tempered or Standard Surface Process Ordinary, Wire Drawing, Laminated Film
Chemical Composition
DIN 17155 C Si Mn P S Al Cr Cu Ni Mo 15Mo3 0.12-0.20 0.10-0.35 0.40-0.90 0.035 0.03 0.25 0.3 0.3 0.25-0.35 13CrMo44 0.08-0.18 0.10-0.35 0.40-0.10 0.035 0.03 0.70-1.10 0.3 0.4-0.6 17Mn4 0.14-0.20 0.4 0.90-1.40 0.035 0.03 0.02 0.25 0.3 0.3 0.1 10CrMo9-10 0.06-0.15 0.5 0.40-0.70 0.035 0.03 2.00-2.50 0.3 0.9-1.0 19Mn6 0.2 0.5 0.90-1.70 0.03 0.025 0.02 0.3 0.3 0.3 0.08 HI 0.16 0.35 0.40/1.20 0.03 0.025 0.02 0.3 0.3 0.3 0.08 HII 0.2 0.35 0.50-1.30 0.035 0.03 0.02 0.25 0.3 0.3 0.1
Scope of Application
DIN 17155 pressure vessel steel plates are widely used in gas, petrochemical and other industries, especially in the manufacture of boilers, medium and high temperature heat-resistant pressure vessels, heat exchangers, spherical tanks, separators, nuclear reactor vessels, oil and gas tanks, liquid oil storage tanks, hydraulic supports, etc.
Equivalent Material
DIN 17155 Material No. EN 10028-2 UNI 5869 BS 1501 A 36087 ASTM JIS G3115 HI 1.0345 P235GH Fe 360 - 1KW 161 Gr. 360 / A 37 RCI A 285 Gr. C-A 414 Gr. C/ SPV 24 HII 1.0425 P265GH Fe 410 - 1KW 161 Gr. 400 / A 42 RCI A 414 Gr. E / 17Mn4 1.0481 P295GH Fe 460 - 1KW 224 Gr. 490 A 47 RCI A 414 Gr. F / SPV 32 19Mn6 1.0473 P355GH Fe 510 - 1KW A 52 RCI A 414 Gr. G SPV 36 15Mo3 1.5415 16Mo3 15 Mo 3 1503 - 243 B 16Mo3 A 204 Gr. B 13CrMo44 1.7335 13CrMo4-5 14 CrMo 4.5 620 Gr. 27 14 CrMo 4.5 A 387 Gr. 12 10CrMo910 1.7380 10CrMo9-10 622 Gr. 31 A 387 Gr. 22
164 Gr. 360
A 516 Gr. 55
164 Gr. 400 /
224 Gr. 400
A 516 Gr. 60
A 516 Gr. 65
