Carbon Steel Coil
Carbon Steel Coil
JIS G3101 SS400/SS490/SS540 Cold Rolled Steel Coil
JIS G3103 pressure vessel steel coil is made of a hot-rolled carbon steel and molybdenum alloy steel for Chinese and high temperature boilers and pressure vessels. The main grades are: SB410, SB450, SB480,SB450M and SB480M.
Big fire special steel, high strength steel plate, steel industry supply and demand, steel suppliers
JIS G3101 SS400/SS490/SS540 Cold Rolled Steel Coil
JIS G3103 is the Japanese standard boiler vessel steel, which is widely used in petroleum, chemical industry, power stations, boilers and other industries, boiler and pressure vessel manufacturing, etc. This kind of vessel steel coil not only has very high strength but also has remarkable toughness, wear resistance, fatigue resistance, impact resistance, corrosion resistance, as well as easy processing and molding properties. It is mostly used in the boiler and petrochemical container manufacturing industry.
Product Parameters
Product Name | JIS G3101 SS400/SS490/SS540 Carbon Steel Coil |
Production Process | Hot Rolling, Cold Rolling |
Material Standards | AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc. |
Width | 45mm-2200mm |
Length | Custom Size |
Thickness | Hot Rolling: 2.75mm-100mm |
Delivery Conditions | Rolling, Annealing, Quenching, Tempered or Standard |
Surface Process | Ordinary, Wire Drawing, Laminated Film |
Chemical Composition
Brand | Carbon | Manganese | Phosphorus | Sulphur |
SS400 | - | - | 0.050 max | 0.050 max |
SS490 | - | - | 0.050 max | 0.050 max |
SS540 | 0.30 max | 1.60 max | 0.040 max | 0.040 max |
Mechanical Properties
Brand | Yield Strength | Tensile Strength | |||
≤ 16 | 16-40 | 40-100 | >100 | - | |
SS400 | 245 | 235 | 215 | 205 | 400-510 |
SS490 | 285 | 275 | 255 | 245 | 490-610 |
SS540 | 400 | 390 | - | - | 540 |
Scope of Application
JIS G3101 scope of application: JIS G3101 steel plate and other steel grade products are suitable for general structural buildings, such as bridges and ships.
